AIC Tillage | 55" Left-Hand Hay Rake Wheel – ASTM A401 | AICT-RW55LH
AIC Tillage AICT-RW55LW is a 55-inch left-hand replacement hay rake wheel built with 40 straight 7 mm ASTM A401 spring steel tines. The wheel features an 80 mm centre pilot with a 6-hole mounting pattern on a 131 mm bolt circle and interchanges with the common P20BG004 / TEP20BG004 left-hand rake wheel family used across many popular agricultural wheel rakes.
Designed for dependable hay and forage pickup, the 40-tine configuration provides consistent crop engagement and movement while the premium spring steel tines provide the strength, flexibility and resilience required for repeated field use. This wheel is used in left-hand rake-wheel positions on compatible Frontier, John Deere, Tonutti, New Holland, H&S, Sitrex, DuraBilt, Enorossi, Vermeer and other wheel rake applications.
Product Specifications
| Part Type | Hay Rake Wheel |
| Wheel Diameter | 55 inch |
| Wheel Direction | Left Hand |
| Number of Tines | 40 |
| Tine Style | Straight |
| Tine Diameter | 7 mm |
| Tine Material | ASTM A401 Spring Steel |
| Centre Pilot | 80 mm (3.15 inch) |
| Mounting Pattern | 6 Hole |
| Bolt Circle | 131 mm (5.16 inch) |
| Replacement Tine | A-P25AG005 / P25AG005 7 mm rake wheel tine |
| Application | Agricultural Wheel Rakes |
| Fitment Check | Confirm left-hand wheel direction, 80 mm centre pilot 6-hole mounting pattern and 131 mm bolt circle |
| Brand | AIC Tillage |
| Part Number | AICT-RW55LW |
Fits Machines
| Frontier | WR1108, WR1112, WR1116, WR1212C, WR1214C, WR1216C, WR1218C WR3008, WR3010, WR3012, WR3310, WR3312, WR3313, WR3315 |
| John Deere | 702, 702A, 704 |
| Tonutti | RTP8, RTP10, RTP12, T6, T9, T13 V10, V12, V14, V16, V18, V20 |
| New Holland | DuraVee 817, 1020, 1225, 1428, 1631, 1833, 2036 H5920, HT152, HT154 ProCart 819, 1022, 1225 |
| H&S | 4112, 4114, 4116 TR7, TR9, TR/9-3W, TR/9-S |
| Sitrex | H90V8, H90V10, H90V12 MKE12, MKE14, MKE16, MKE18, MKE20 MX8, MX10, QR8, QR10, QR12, QRX12, QRX14 |
| DuraBilt | HCL8, HCL10, HCL12 |
| Enorossi | BAT 8, BAT 10, BAT 12 55-inch wheel configurations |
| Vermeer | WR20, WR22, WR24 |
| Other Applications | Select Gehl, M&W, OTMA, Rossi and Walton wheel rakes using the same P20BG004-style left-hand wheel and mounting configuration |
Cross Reference
| AIC Tillage | AICT-RW55LW |
| Tonutti | P20BG004 TEP20BG004 |
| John Deere / Frontier | AE57870 HPT174 5HPT174 |
| New Holland | 86729949 |
| H&S / M&W | P20BG004 P20BG091 |
| Sitrex | 210181 P20BG004 P20BG091 |
| Gehl / OTMA / Rossi | P20BG004 |
| Vermeer | 773840 773875 |
| Other Aftermarket Part Numbers | A-P20BG004 804-P20BG004 127-P20BG004 RW178 W16-0802 W16-0806 W16-0812 |
