Walterscheid | PTO Flange Yoke FG 2600 | 195mm 8-Bolt | 153947E
Walterscheid 153947E is a genuine FG 2600 PTO flange yoke, OEM 1153947, designed for compatible Walterscheid W2600 and P600 Series PTO driveline assemblies. This FG-style yoke features a 195 mm diameter, 8-bolt flange with a 165 mm bolt circle and AZ98H9 external centering configuration.
Designed for the nominal 42 ร 104 mm universal-joint cross size associated with the Walterscheid 2600 / P600 cross-kit series, the yoke features 42 mm bearing bores, a 120 mm yoke width (B) and a 119 mm bearing-eye-to-end length (L). Its flange connection includes eight evenly spaced 12.5 mm mounting holes, a 98 mm nominal external centering diameter and a 17 mm flange thickness, excluding the 2 mm centering feature.
Before ordering, verify the original Walterscheid OEM number, compatible cross dimensions, flange diameter, bolt circle, mounting-hole pattern and centering configuration against the original component. Matching cross dimensions alone do not guarantee compatibility with every driveline assembly or cross-kit configuration. Part 153947E is the store SKU for genuine Walterscheid OEM 1153947.
Product Specifications
| Specification | Details |
|---|---|
| Part Number | 153947E |
| Walterscheid OEM Number | 1153947 |
| Part Type | FG Flange Yoke |
| Manufacturer Designation | FG 2600 D195 TK165 B12,5-8 AZ98H9 L119 |
| Walterscheid Driveline Series | W2600 / P600 |
| Compatible Cross-Kit Series | 2600 / P600 |
| Compatible Cross Size | 42 ร 104 mm |
| Bearing Bore Diameter (d) | 42 mm |
| Cross Overall Length (X) | 104 mm |
| Yoke Width (B) | 120 mm |
| Bearing Eye-to-End Length (L) | 119 mm |
| Flange Diameter (D1) | 195 mm |
| Bolt Circle Diameter (D2) | 165 mm |
| Mounting Holes | 8 ร 12.5 mm |
| Centering Configuration | AZ98H9 (External) |
| Centering Diameter (D3) | 98 mm |
| Centering Length (L2) | 2 mm |
| Flange Thickness | 17 mm (excluding centering) |
| Manufacturer Drawing | 26.15.124+ |
